FEATURES:
SPECIFICATIONS
DSP:
A/D Converter: |
18 bit, 128 x oversampled delta-sigma stereo |
D/A Converter: |
20 bit 64 x oversampled |
Sampling Frequency: |
44.1 kHz |
Architecture: |
(2) Static-Dynamic Instruction Set Computer (S-DISC) |
Digital Signal Path Width: |
24 bits (144.5 dB) |
Internal Data Path Width: |
48 bits (289 dB) |
Dynamic Delay Memory: |
(2)64k x 20 bits (2 x 1.49 seconds) |
Static Delay Memory: |
(2) 256 24-bit registers (2 x5.8 milliseconds) |
Data ALU Processing: |
11.3 MIPS |
Address ALU Processing: |
16.9 MIPS |
Multiplier Size: |
24 bits x 24 bits |
General:
Connectors: |
1/4" Unbalanced Inpus (4) & Outputs (4) |
Nominal Input Level: |
-10dBV, +4dbu (Software selectable) |
Maximum Input Level: |
+18 dBu |
Input Impedance: |
10k Ohms |
Nominal Output Level: |
-10dBV, +4 dBu switchable |
Maximum Output Level: |
+18 dBu |
Output Impedance: |
470 Ohms |
Frequency Response: |
20 Hz. - 20kHz. ア3 dB |
S/N Ratio: |
Greater than 96 dB; ref =max signal, 22 kHz measurement bandwidth (A-Weighted) |
THD: |
Less than 0.03% (1 kHz) |
MIDI: |
In, Out/Thru, Full MIDI Implementation |
Other Specs:
Memory Capacity: |
Factory: 100 Programs, User: 100 Programs |
Power Requirements: |
US and Canada: 120 VAC, 60 Hz; Japan: 100 VAC, 50/60 Hz; Europe: 230 VAC, 50 Hz; UK: 240 VAC, 50 Hz |
Power Consumption: |
30 Watts |
Size: |
9.25" (D) X 19" (W) X 3.5" (H) |
Net Weight: |
10.25 lbs, 4.64 kg |
Shipping Weight: |
13 lbs, 5.9kg |
